High Quality Customized Turned Parts with great precision & Accuracy can be made very effectively by our CNC Machines in Metals like Brass, Copper, Stainless steel & Mild Steel and Aluminum.
We Make the Components with Accuracy of as Low as 10 Microns.
Salient Features of CNC Turned Parts :
- Very High Quality Parts can be made of Turning diameter between 10mm to 70mm
- Accuracy of 10 to 15 microns can be achieved with high precision
- Provides high quality surface finish
- High Processing accuracy to achieve Zero defect products leading to 0 PPM
- Ideal for highly customized Precision components
- Complex parts can be made effectively
- Small batch quantity products can be undertaken which is of benefits to customers whose requirements are small or change at short notice
- Any Kind of special turned parts can be made as per customer's specifications
Threads :
- ISO Metric MM, PG, BSW, BSP, BSB, BSF, BA, NPT, NPTF, UNC, UNF, UNEF etc
- Almost any threads as per custom specification
Material :
- Free Cutting Brass IS 319 Type (I) or BS 249 Type (I) or High Grade
- Any Special Brass Material Composition as per customers requirement
- Stainless Steel Turning Grades like 303, 304 etc
- Mild Steel Grades like EN 1A (BS 970 230M07) etc
- Aluminum Turning Grades like 1070 etc
Finish And Coating :
- Natural Clean
- Nickel
- Silver
- Tin
- White, Yellow or Blue Zinc
Any kind of CNC Turned Components can be developed As Per Customers Specifications. |
